Affordable Mini Desktop CNC Router Price TPM6090 For Sale
Rating:
Loading...Mini desktop CNC Router 6090 mainly used in the advertising industry, woodworking industry, metal processing industry. such as LED word, acrylic lighting word, wood, MDF, crafts, cabinet door, copper, aluminum cutting and engraving.
Working Video:
Affordable mini desktop CNC Router machine price TPM6090 for sale use for 2d 3d projects carving, which belonging to mini cnc router table size. So it is suitable for personal artisan and homework.
Features of Mini desktop CNC Router TPM6090:
1. Adopt cast iron structure design, which through annealing and destressing process, then can ensure the strength and rigidity of the of the machine body.
2. With intelligent motion DSP control system, easy to use and operate.
3. Independent controlling cabinet, separation of strong electricity and weak electricity to make the maintenance more convenient.
4. High precision ball screw of X Y Z axis, which move smoothly to ensure precision.
Application of Mini Desktop CNC Router Projects:
Advertising industry: such as LED words, bevel edge word, acrylic lighting word and Sign processing.
Woodworking industry: such as building model, wood, MDF, Solid wood, wooden door and wooden cabinet etc.
Metal industry: such as carving on copper, aluminum, iron plate etc.
Technical Parameters of Mini CNC Router TPM6090:
| Model | TPM6090 |
| Working Area | 600*900mm (tabletop) |
| Max.Material Height | 150mm |
| Spindle Power | Water Cooling 2.2kw Spindle |
| Spindle RPM | 0~24000rpm |
| Control System | RichAuto-A11 DSP control system |
| Motor and Driver | Leadshine Stepper Motor and driver |
| Transmission Way | X,Y,Z with Taiwan TBI ball screw transmission |
| Max Rapid Travel Rate | 33m/min |
| Max Working Speed | 25m/min |
| Repeat Precision | 0.025mm |
| Table surface | T-slot aluminum with PVC protection |
| Frame | Cast Iron |
| Working environment temperature | 0-45℃ |
| Relative Humidity | 30%-75% |
| Command language | G code |
| Power supply | AC220V or 380V, 50-60HZ |
| Net/Gross Weight | 300/380kg |
Machine Parts of Mini CNC Router Price TPM6090 table size:
Samples of Mini CNC Router Projects:
Packing and Shipping Details:
1). Outside package: with standard marine export plywood case.
2). Inner package: use stretchy film and plastic film for humidity.
3). Mini desktop CNC router 6090 machine packing size: 1250*1550*1820mm, GW: 350kg
Mini desktop CNC router 6090 size can shipping within 5-7working days when get your payment.
1). Machine has been adjusted and test 48 hours before delivery.
2). English software, User manual and detailed installation & training video in USB when delivery.
3). Some extra spare parts in the tools box (Such as electrical components, limit switches etc.)
Our Service of Mini Desktop CNC Router Price TPM6090:
1.) Small size cnc machine warranty: two years on parts when get machine, 3 years for free repair. Life-time technical support.
2.) Machine spare parts and repair service is offered in lifetime when get machine.
4.) When you need help, there are 10 oversea technicians and 5 online engineers, 24 hours technical online support by E-mail,Skype online contact software.
5.) 5-7 days free machine training when visit our factory .
6.) International quality certificate: FDA,CE, ISO9001 SGS etc. so can meet customs requirements
If you are interested in this small size cnc machine projects, then contact with our sales : Get A Gree Quote
